Description
| Technical characteristics |  |
|
- Productivity (for 5.0 l ), bottles per hour: 800
- Number of mold cavities, pcs: 1
- Neck Range (diameter), mm: 45 (47)
- Maximum Container Diameter, mm: 220
- Maximum Container Height, mm: 430
- Capacity range of the Container, L: 5.0-10.0
- Preblow-up pressure*, up to, mPa: 1.6
- Main blow-up pressure*, up to, mPa: 2.5
- Control pressure, up to, mPa: 0,8
- Air consumption*, m3/min: 2.6
- Fluid flow rate, m3/hour: 1.3
- Number of heating elements, pcs: 30
- Installed power, kW: 18
- Power consumption, kW: 16.8
- Overall dimensions, mm (LxWxH): 7350x2800x2200(2500)
- Total weigth, kg: ~4700
|
