Description
| Technical characteristics |  |
|
- Productivity (for 1.5 l ), bottles per hour: 2400
- Number of mold cavities, pcs: 3
- Neck Range (diameter), mm: 28 (38)
- Maximum Container Diameter, mm: 105
- Maximum Container Height, mm: 350
- Capacity range of the Container, L: 0.25-2.2
- Preblow-up pressure*, up to, mPa: 1.6
- Main blow-up pressure*, up to, mPa: 4.0
- Control pressure, up to, mPa: 0,8
- Air consumption*, m3/min: 3.5
- Fluid flow rate, m3/hour: 0.9
- Number of heating elements, pcs: 24
- Installed power, kW: 14
- Power consumption, kW: 10
- Overall dimensions, mm (LxWxH): 5600x2800x2200(2500)
- Total weigth, kg: ~3000
|
Video | |
|
