Description
| Technical characteristics |  |
|
- Productivity (for 1.5 l ), bottles per hour: 7500
- Number of mold cavities, pcs: 6
- Neck Range (diameter), mm: 28 (38)
- Maximum Container Diameter, mm: 105
- Maximum Container Height, mm: 350
- Capacity range of the Container, L: 0.25-2.2
- Preblow-up pressure*, up to, mPa: 1.6
- Main blow-up pressure*, up to, mPa: 4.0
- Control pressure, up to, mPa: 0,8
- Air consumption*, m3/min: 9.5
- Fluid flow rate, m3/hour: 1.5
- Number of heating elements, pcs: 42
- Installed power, kW: 70
- Power consumption, kW: 45
- Overall dimensions, mm (LxWxH): 11000x4300x2200(3300)
- Total weigth, kg: ~6000
|
Video | |
|
|
Price for set | |
|
«Machinery & Technology» Ltd follows the principle of personal approach to a client and forming the final price of the equipment, according to the individual requirements of the client. In order to receive the price list of the equipment you are interested in, please, fill in the following form.
Equipment inquiries
Check the availability, cost and characteristics of the equipment by phone or email.
