Description
| Technical characteristics |  |
|
- Productivity (for 1.5 l ), bottles per hour: 1450
- Number of mold cavities, pcs: 2
- Neck Range (diameter), mm: 45 (36,47)
- Maximum Container Diameter, mm: 180
- Maximum Container Height, mm: 380
- Capacity range of the Container, L: 2.0-6.0
- Preblow-up pressure*, up to, mPa: 1.6
- Main blow-up pressure*, up to, mPa: 2.5
- Control pressure, up to, mPa: 0,8
- Air consumption*, m3/min: 4.72
- Fluid flow rate, m3/hour: 1.3
- Number of heating elements, pcs: 7
- Installed power, kW: 18
- Power consumption, kW: 16.8
- Overall dimensions, mm (LxWxH): 7300x4000x2200(2500)
- Total weigth, kg: ~4500
|
Video | |
|
Equipment inquiries
Check the availability, cost and characteristics of the equipment by phone or email.
